Hi there! My name is James, and I'm the customer support specialist for ModsPioneers. Whether you have a question about our 12V/24V RV AC units, need some advice on installation, or just want to talk about your next off-grid adventure, I'm here to help.
The best way to get in touch is by using the form below. Please provide as much detail as you can about your question or vehicle so I can give you the most accurate and helpful response.
Let's Talk About Your Off-Grid Cooling Needs
Authorized installer in the Southern California
Frequently Asked Questions
What are the recommended wire gauge and fuse size for the AC unit?
The 12V model comes with a pre-connected 6AWG power cable and a 100A in-line fuse, its total length is 13.1 feet, with 2.85 feet inside the AC unit and the remaining 10.27 feet extending from the bottom of the unit. For the 24V model, the wire gauge is 8AWG. You can connect it directly to your battery bank or to a bus bar rated for 60-70 amps. In most cases, you won't need to purchase a power cable separately.
Can the AC unit be installed on a slanted roof?
Yes, the unit can be installed on a slanted roof, but for proper condensation drainage, the angle must not exceed 15 degrees.
What are the roof thickness requirements for installation?
There are two requirements to consider regarding your RV's roof thickness. First, the included mounting rods are for roofs up to 2.5 inches thick. If your roof is thicker, you'll need to use longer rods. Second, the height from the top of your roof to the bottom of your ceiling must not exceed 4 inches to allow access to the air filter for cleaning.
What's the recommended battery capacity?
A single 12.8V 100Ah lithium battery can run the 12V AC model for about 2 to 3 hours. However, for regular off-grid use, we recommend a 300Ah lithium battery bank to ensure you have plenty of power for continuous cooling and all your other needs.
